Product Details:
Payment & Shipping Terms:
|
| Name: | Veterinary Autoclave | Application: | Veterinary And Research Us |
|---|---|---|---|
| Chamber Size: | 110 Liters To 600 Liters | Door Mechanical: | Vertical Sliding Door |
| Material Optional: | 304 Chamber Or 316 L | Chamber Structure: | Rectangle |
| Door Quantity: | Single Or Pass Through | Sterilization Temperature: | 105 To 132 Degree |
| Highlight: | Veterinary Medical Equipment,Veterinary Medical Devices |
||
Specification
1. The advanced vertical veterinary autoclave line features top loading sterilizers from Medpharm with fast cooling, optional drying and waste treatment options.
2. The advanced veterinary line provides a single solution for the full spectrum of sterilization needs including liquids, culture media, instruments, glassware, plastics, pipette tips, biological waste, contaminated media and other veterinary items.
3.The autoclave is designed to accommodate a wide range of applications. The user can choose to add the features needed according to the sterilizer’s intended use.
4. The advanced veterinary autoclave line is available in an unmatched range of floor standing models with chamber volumes of 110liters to 600 liters.
|
Model |
Chamber Size |
Overall Size |
Net Weight |
Steam |
Water |
Power |
|
W*H*D mm |
W*H*D mm |
Kg |
Kg/cycle |
Kg/cycle |
KVA |
|
|
MD-0.11V |
400*400*700 |
1000*1800*1040 |
650 |
14 |
215 |
2 |
|
MD-0.16V |
400*400*1000 |
1000*1800*1340 |
700 |
16 |
220 |
2 |
|
MD-0.20V |
400*400*1300 |
1000*1800*1640 |
750 |
18 |
225 |
2 |
|
MD-0.24V |
600*600*670 |
1200*2000*1010 |
800 |
20 |
230 |
2 |
|
MD-0.30V |
600*600*840 |
1200*2000*1180 |
850 |
22 |
235 |
2 |
|
MD-0.36V |
600*600*1000 |
1200*2000*1340 |
900 |
25 |
240 |
2 |
|
MD-0.45V |
600*600*1250 |
1200*2000*1590 |
980 |
27 |
250 |
2 |
|
MD-0.60V |
600*600*1670 |
1200*2000*2010 |
1100 |
30 |
260 |
3 |
Program Parameter
|
Cycle name |
Further details |
Application |
|
Instruments/Tools |
3 times Vacuum, expose temperature 132℃, expose time 8 min, drying time 5 min. |
Solid materials to be sterilized: |
|
Clothing |
3 times Vacuum, expose temperature 121℃, expose time 15 min, drying time 25 min. |
Materials to be sterilized from which air can’t be easily displaced |
|
User Programmable |
All preset parameters can be reset; Multiple customized programs can be set and stored by user. |
Customized |
|
Test programs |
||
|
B-D Test |
3 times Vacuum, expose temperature 134℃, expose time 4 min, drying time 3 min. |
Test program |
|
Vacuum Leakage Test |
Test the chamber connecting parts’ tightness effect. It’s important to ensure the sterilization effect. |
Test program |
Description
The autoclave is an integral part of the veterinary practice, being at the center of the infection
control process. Medpharm autoclaves use steam as the sterilizing agent—at temperatures
ranging from 250° F to 273° F- to completely sterilize surgical and non-surgical instruments
Steam sterilization of veterinary instruments is safe and effective. Medpharm sterilizers are
designed for all your infection control needs.
Applications
Veterinary and research use
Competitive Advantage
Clean and no second pollution
Brochure load down from here
Medpharm medical large steam autoclave brochure.pdf
