Product Details:
Payment & Shipping Terms:
|
| Name: | Veterinary Autoclave | Application: | Culture Media,Substrate,Media |
|---|---|---|---|
| Door Mechanical: | Vertical Sliding Door Or Hinge Door | Material Optional: | 304 Or 316L Chamber And Jacket |
| Chamber Structure: | Rectangle Horizontal Type | Door: | Single Or Pass Through |
| Cycles: | 15 Reset Programs | ||
| Highlight: | Veterinary Medical Devices,Veterinary Medical Equipment |
||
Specification
| Model | MDB-0.36 | |
| Style | Single Door (S) | Double Door (D) |
| Overall Dimension | 1350*1800*1280mm | 1350*1800*13400mm |
| Chamber | 600*600*1000mm ,Vol: 360L, Material: STS 316L | |
| Net weight | 800kg | |
| Loading System | Loading Car,Loading Shelf | |
| Temperature |
105°C to 134°C |
|
| Air Removal | Vacuum / Gravity | |
| Controls | Microprocessor | |
| Display | 5.7inch color touch screen | |
| Printer | Built-in printer | |
| Power |
Our ordinary electrical power is AC380, 50Hz, 3phase, N, E |
|
| Steam feeding |
External steam supply, 0.4---0.7MPa, saturated steam offer by user Built-in electrically heated steam generator (Option) Built-in industrial steam heated steam generator (Option) Combining steam generators: individual electrically heated steam generators or natural gas heated steam generators(Option) |
|
| Water |
Softened water (Hardness <50ppm, pH Neutral) is at least requirement for the autoclaves’ durability and safety of the goods to be sterilized. Water pressure: 0.15----0.3MPa |
|
| Compressed air |
Oil free compressed air is important to the autoclave’s running. Oil free silence air-compressor is optional for user’s selection. Compressed air pressure: 0.5---0.8MPa |
|
Cycles
|
Cycle name |
Further details |
Application |
|
Instruments/Tools |
3 times Vacuum, expose temperature 132℃, expose time 8 min, drying time 5 min. |
Solid materials to be sterilized: |
|
Clothing |
3 times Vacuum, expose temperature 121℃, expose time 15 min, drying time 25 min. |
Materials to be sterilized from which air can’t be easily displaced |
|
User Programmable |
All preset parameters can be reset; Multiple customized programs can be set and stored by user. |
Customized |
|
Test cycles |
||
|
B-D Test |
3 times Vacuum, expose temperature 134℃, expose time 4 min, drying time 3 min. |
Test program |
|
Vacuum Leak Test |
Test the chamber connecting parts’ tightness effect. It’s important to ensure the sterilization effect. |
Test program |
Description
The autoclave is an integral part of the veterinary practice, being at the center of the infection
control process. Medpharm autoclaves use steam as the sterilizing agent—at temperatures
ranging from 250° F to 273° F- to completely sterilize surgical and non-surgical instruments
Steam sterilization of veterinary instruments is safe and effective. Medpharm sterilizers are
designed for all your infection control needs.
Applications
Veterinary and research use
